Anti-Laser Blackness

April 22, 2019

One book on my bookshelf is Nassim Nicholas Taleb's, "The Black Swan: The Impact of the Highly Improbable," a 2007 exposition of his black swan theory that rare events have a huge impact on economics and culture.[1] In my corporate research days, technological black swans were known as disruptive technologies. One example of these is digital photography, a technology that disrupted chemical photography and caused the decline of the Eastman Kodak Company, a company in business since 1888. I wrote about Kodak in an earlier article (George Eastman and Kodak, February 21, 2012)

The black swan metaphor for an unlikely event is usually traced back to the Roman poet, Juvenal (Decimus Iunius Iuvenalis, fl. 2nd century AD), who writes about a niger cygnus, but there was an earlier mention by Lucretius (Titus Lucretius Carus, 99 BC - c.55 BC) in book II of his "De rerum natura" where he writes how unlikely it would be that, "...Swans turn black from seed of black, or be of any single varied color you might want" ("... nigros fieri nigro de semine cycnos aut alio quovis uno varioque colore").[2]

Other authors in antiquity, however, were more likely to write about white crows than black swans.[2] This is probably a consequence of the paucity of swans and an abundance of crows. Juvenal, himself, wrote in his Satire VII that a "Happy man is rare - rarer than a white crow" ("Felix ille tamen corvo quoque rarior albo").[2] The ancient Greeks had the expression "seeing a white crow" ("λευκον ιδειν κορακα"). Not surprisingly, Aristophanes (c.446 BC - c.386 BC) mentions white crows in his play, The Birds.

A black swan, Cygnus atratus

A black swan, Cygnus atratus.

For most of history, a black swan was a metaphor for an impossibility. However, the first Europeans who came to Australia in the 17th century discovered black swans there.

Cygnus atratus, which have reddish bills, are found mostly in southeast and southwest regions of Australia.

(Illustration by Neville William Cayley from the 1931 book, "What Bird Is That?" via Wikimedia Commons)


To complement the ornithologists' interest in black swan habitats and migration, physicists have spent a lot of time in study of the quality of blackness and the development of very black materials. When 19th century physicists needed a very black object for an optical experiment, they would form layers of soot on glass. Soot is condensed from the smoke of incompletely combusted hydrocarbons. A well prepared layer of soot will reflect less than 1% of visible light.

The 99% blackness of soot is quite black; but, as I wrote in a previous article (Very White and Very Black, November 23, 2011), a more advanced form of soot, carbon nanotubes, can do much better. Arrays of vertically-aligned carbon nanotubes are quite black over a wide range of wavelength, and they can absorb more than 99.955% of incident light at visible wavelengths.[3-4] The supposed mechanism is that the forest of nanotubes has a multitude of holes and gaps to trap light; that is, incident light must make many multiple reflections to exit.

NASA vertically-aligned carbon nanotube absorber

A super-black vertically-aligned carbon nanotube optical absorber created by NASA.

The upper image has a portion removed to show the vertical alignment of the nanotubes, and the lower image shows the surface at high resolution. The scale bar is a 50 micrometer marker.

This material absorbs 99.5% of visible and ultraviolet light, but only 98% of far-infrared light. NASA is concerned not only with the optical absorption property, but with the complementary emissivity. Super-black materials will efficiently radiate heat energy to keep spacecraft sensors and electronic components cool.[5]

(Images by Stephanie Getty, NASA Goddard)


Scientists always strive for perfection. While 99.955% appears to be sufficient for any useful absorber, there's always the allure of that magical 100%. The laser is a perfect emitter of light of a specific wavelength, and a time-reversed laser would act as a perfect light absorber, an anti-laser. An anti-laser operating at microwave frequencies, based on random scattering, has been achieved by scientists at the Vienna University of Technology (TU Wien, Vienna, Austria) and the Université Côte d'Azur (CNRS, Nice, France).[6-7] Says Stefan Rotter, a professor at the Institute for Theoretical Physics at TU Wien,

"Because of this time-reversal analogy to a laser, such absorbers are called anti-lasers... So far, anti-lasers have only been realized in one-dimensional structures onto which laser light was directed from opposite sides. Our approach is much more general: we were able to show that even arbitrarily complicated structures in two or three dimensions can perfectly absorb a suitably tailored wave. In this way, this novel concept can also be used for a much wider range of applications."[6-7]

The TU Wien device is different from previous coherent perfect absorbers (CPAs) since it's based on a disordered medium. Its near-perfect absorption of electromagnetic radiation is attained resonantly by multiple scattering.[6] Not surprisingly, the device was developed using data from computer simulations before being experimentally verified.[7] As Rotter explains,

"Waves that are being scattered in a complex way are really all around us - think about a mobile phone signal that is reflected several times before it reaches your cell phone... This multiple scattering is made practical use of in so-called random lasers. Such exotic lasers are based on a disordered medium with a random internal structure that can trap light and emit a very complicated, system-specific laser field when supplied with energy."[7]

TU Wien random anti-laser

The experimental setup of the Vienna University of Technology (TU Wien) random anti-laser. Ernest Rutherford once said that "An alleged scientific discovery has no merit unless it can be explained to a barmaid." This device is as simple as arranging beer glasses, albeit in a special way. It consists of a waveguide filled with randomly placed Teflon cylinders. The top plate of the waveguide, moved aside to reveal the cylinders, has a central microwave antenna that absorbs the microwaves. (TU Wien image, with added inset.)


As shown in the above photo, the device consists of a microwave waveguide and a central absorbing antenna filled with a random arrangement of Teflon cylinders. The cylinders act like stones in a puddle of water reflecting water waves; but, in this case, they scatter microwaves to create a complex wave pattern in which the reflected microwaves overlap and interfere with each other.[7] This enables efficient absorption by the central antenna, and this absorption was experimentally measured to be 99.8%.[7]

Scientists at Duke University have modified a metamaterial absorber they published in 2017 to produce their own anti-laser.[8-9] The metamaterial is built from zirconia ceramic dielectric that had surface cylinders like the face of a Lego brick (see photo).[9] Says Duke research leader, Willie Padilla, a professor in Duke's Department of Electrical and Computer Engineering, "We've studied this system before as a perfect absorber, but now we've figured out that this device can be configured to be a CPA as well."[9]

Duke University zirconia ceramic dielectric metamaterial absorber.

Duke University zirconia ceramic dielectric metamaterial absorber.

As Kebin Fan, a research assistant professor at Duke explains, "Typical CPAs have only one variable, the material's thickness... We have three: the cylinders' radius, height and periodicity. This gives us a lot more room to tailor these modes and put them in the frequency spectrum where we want them, giving us a lot of flexibility for tailoring the CPAs."[9]

(W. Padilla/Duke University image, cropped.)


While the absorbance of these devices still falls short of perfection, such anti-lasers could have some useful applications, such as hyperspectral imaging and energy harvesting.[8] They might also be important where focused energy is used, as in kidney stone lithotripsy.[7]

References:

  1. Nassim Nicholas Taleb, "The Black Swan: The Impact of the Highly Improbable," Random House (April 17, 2007), 366 pp., ISBN: 978-1400063512 (via Amazon).
  2. Antonio Marco Martinez, "Nihil Novum sub Sole - 1001 deeds, sayings, curiosities and anecdotes of the ancient world, Antiquitatem Website.
  3. Zu-Po Yang, Lijie Ci, James A. Bur, Shawn-Yu Lin and Pulickel M. Ajayan, "Experimental Observation of an Extremely Dark Material Made By a Low-Density Nanotube Array," Nano Lett., vol. 8, no. 2 (February, 2008), pp 446-451.
  4. Kohei Mizuno, Juntaro Ishii, Hideo Kishida, Yuhei Hayamizu, Satoshi Yasuda, Don N. Futaba, Motoo Yumura and Kenji Hata, "A black body absorber from vertically aligned single-walled carbon nanotubes," Proc. Natl. Acad. Sci., vol. 106, no. 15 (April 14, 2009), pp. 6044-6047.
  5. Lori Keesey and Ed Campion, "NASA Develops Super-Black Material That Absorbs Light Across Multiple Wavelength Bands," NASA Goddard Press Release No. 11-070, November 8, 2011.
  6. Kevin Pichler, Matthias Kühmayer, Julian Böhm, Andre Brandstötter, Philipp Ambichl, Ulrich Kuhl, and Stefan Rotter, "Random anti-lasing through coherent perfect absorption in a disordered medium," Nature (March 4, 2019), https://doi.org/10.1038/s41586-019-0971-3.
  7. Florian Aigner, "The Random Anti-Laser," Vienna University of Technology Press Release, no. 11/2019, March 5, 2019.
  8. Jonathan Y. Suen, Kebin Fan, and Willie J. Padilla, "A Zero-Rank, Maximum Nullity Perfect Electromagnetic Wave Absorber," Advanced Optical Materials (January 28, 2019), Article no. 1801632, DOI: 10.1002/adom.201801632.
  9. Ken Kingery, "Researchers Discover Anti-Laser Masquerading as Perfect Absorber," Duke University Press Release, February 15, 2019.
