Boiling Crisis

May 20, 2019

Bubbles might be something that you rarely think about, but they're ubiquitous in your life. When you arise in the morning, there are bubbles in your toothpaste, mouthwash, soap, shampoo, shaving cream, boiling water for your oatmeal, and foam atop your coffee. If you're a hearty breakfast person, there are bubbles in your bacon grease as it fries. There are other examples throughout your working day, and likely many more on weekends.

The Three Witches from Macbeth, Wellcome 26345-V0025894

A famous literary reference to bubbles is found in Shakespeare's Macbeth (c.1605), where the Three Witches are tending their witches' brew and chanting, "Double, double toil and trouble; Fire burn and caldron bubble."

English allowed multiple spellings in Shakespeare's time, and some are carried over today, when caldron is also spelled as cauldron.

(Portion of a 19th century woodcut, image 26345-V0025894 from the Wellcome Trust, via Wikimedia Commons. Click for larger image.)

Greek philosopher, Aristotle (384-322 BC) had a simple explanation for the observation that bubbles rise in a liquid. In Aristotle's version of physics, things had a tendency to move to their natural place. In the case of the air in a bubble, the natural place is above the water. The four elements of classical antiquity were arrayed in successive layers above the center of the universe, seen at that time as the center of the Earth, with Earth being the lowest, layered above by Water, Air and Fire.

Bubbles are usually observed when a liquid is heated beyond its boiling point and its vapors coalesce inside it. There is, however, another way to create bubbles in a liquid, and that's by a mechanical action or flow condition that causes a rapid change in pressure and produces small bubbles where the pressure is relatively low. This would be merely a scientific curiosity were it not for shock waves that are produced when these bubbles collapse.

This phenomenon is called cavitation, and it's responsible for damage to many types of machines operating in fluids. As I wrote in a previous article (Cavitation, October 16, 2017), cavitation causes damage to ship propeller blades, hydraulic pump impellers, and pipe bends that cause sudden change in the direction of rapidly moving liquid.

The term, "cavitation," was coined by R. E. Froude and first used by Barnaby and Thornycroft in 1893.[1] Barnaby and Parsons determined that the propeller failure of the HMS Daring, a British warship was caused by cavitation. Although not by name, cavitation was earlier described Leonhard Euler (1707-1783) in his 1754 paper, "Théorie plus complette des machines qui sont mises en mouvement par la réaction de l'eau (A more complete theory of machines that are set in motion by reaction with water).[2]

The cavitation phenomenon was of interest to another physics luminary after Euler. Rayleigh analyzed the collapse of a void in a large liquid mass in 1917,[3] and the Rayleigh–Plesset equation describes the dynamics of cavitation using the simplifying assumption that the void is a sphere. Actual voids are more hemispherical in shape, since they need to be nucleated on a surface.

The first lesson learned by any cook is how to boil water.

While addition of salt does cause the boiling temperature to increase, the effect is so small that the temperature change for an amount added in cooking (as for cooking pasta) would hardly register on a thermometer.

(Photograph via Wikimedia Commons)

Bubbles can be created by other means than the mechanical action in cavitation. Transient local heating in a liquid by a focused laser pulse or an electrical discharge, will create a bubble. The pressure increase in a bubble during collapse will increase the temperature of the bubble gases, sometimes to thousands of degrees kelvin, and this can result in an effect called sonoluminescence in which light is emitted from the bubble.

Liquids can sometimes be put into a superheated state in which the boiling temperature is exceeded, but boiling does not occur. That happens in smooth containers for which there are no nucleation sites for bubbles. To prevent superheating and ensure streams of small bubbles rather than large bubbles that might eject liquid from beakers, chemists add boiling stones to their beakers. These small, rough, irregularly-shaped ceramic pieces provide nucleation sites for bubbles.

The nucleation of bubbles at surfaces is an important factor in the transport of heat from solids to liquids, since the thermal conductivity of gases is usually lower than that of liquids. The low thermal conductivity of air is the principle behind insulating foams that contain air pockets, and an insulating layer of vapor is responsible for the longevity of water droplets placed in a very hot pan first noticed by German physician, Johann Gottlob Leidenfrost in 1756.

The eponymous Leidenfrost effect occurs when a thin vapor layer is formed below a droplet placed on a surface that's above the liquid's boiling point. The vapor barrier offers thermal insulation, the liquid can't extract heat from the pan at a rapid rate, so its evaporation is inhibited.

While the Leidenfrost effect is a nice party trick, a vapor layer can cause a problem in heat exchangers. This is especially true in a regime called a boiling crisis, which is the point at which so many bubbles are nucleated on a hot surface that they coalesce into a continuous sheet of vapor. This vapor sheet seriously inhibits heat transfer to the liquid, thereby counteracting the purpose of the heat exchanger. For this reason, such devices as nuclear reactors are operated only in a safe regime far below the temperatures that could trigger a boiling crisis.

A boiling crisis is not a problem for your electric coffee maker, unless you like your coffee really hot, since the phenomenon only happens for water at one atmosphere pressure when the heat flux across the solid-liquid interface nears a megawatt per square meter. The heat flux at which a boiling crisis occurs at a horizontal surface can be estimated for large objects with very small surface curvature from the following equation, derived by Novak Zuber in 1959:[4]

In this equation, q is the critical heat flux, L is the latent heat of vaporization, ρ_L and ρ_v are the densities of the liquid and vapor, σ is the surface tension, and g is the gravitational acceleration. It's interesting to note from this equation that the critical heat flux is zero in a weightless environment, where g = 0.

This boiling crisis is important to nuclear power plants, which must exchange large quantities of heat in order to drive turbines for electrical power generation. Since a boiling crisis would lead to a runaway weakening or melting of material, nuclear plants are designed to operate at safe levels that are far below boiling crisis conditions. A team of scientists and engineers from the Department of Nuclear Science and Engineering, the Massachusetts Institute of Technology (Cambridge, Massachusetts) has recently investigated the boiling crisis in detail and has published their findings in a recent issue of Physical Review Letters.[5-6]

Proper heat exchange in nuclear reactors is important, since it prevents overheating that could potentially lead to a meltdown.[6] For safety reasons, regulations require that nuclear plants operate at heat fluxes that are no more than 75 percent of the critical heat flux, the heat flux for a boiling crisis.[6] Since the boiling crisis process is not well understood, the critical heat flux is calculated conservatively, so the power produced by a nuclear reactor is less than it might be.[6]

The MIT team is led by assistant professor, Matteo Bucci, and it includes graduate students Limiao Zhang and Jee Hyun Seong.[6] This research has application beyond nuclear reactors, since effective heat transfer is required in other types of power plants, and also for liquid cooling of high-performance computer chips.[6] Says Bucci

"Even in the 21st century, we talk about an energy revolution, a computer revolution, nanoscale transistors, all kinds of great things. Yet, still in this century, and maybe even in the next century, these are all limited by heat transfer."[6]

The critical heat flux equation written above was derived using some simplifying assumptions. In actual cases, small changes in material types and surface texture can have large affects, as evidenced when limescale disrupts water heater performance. The MIT team modeled the boiling crisis by taking such factors into account, and they found that the phenomenon is much like the flow of traffic in a city, or how disease epidemics spread.[6]

In the traffic case, increasing the number of cars beyond a certain threshold results in a greater likelihood that they will bunch up into a traffic jam. The bubbles on a heated surface show a similar behavior in which bubbles will crowd together and merge when a critical density is reached.[6]

Color map of heat transfer rate from a metal surface

A color map of the rate of heat transfer from a metal surface, with red the highest and blue the lowest.

The large blue areas show the beginning of a boiling crisis.

(MIT image by Zhang, Seong, and Bucci.[5])

Says Bucci, "The boiling crisis is essentially the result of an accumulation of bubbles that merge and coalesce with each other, which leads to failure of the surface... We can take inspiration, take the same approach to model boiling as is used to model traffic jams."[6] Fortunately, such traffic models are well developed.[6] Modifying the surface texture to minimize the interaction between bubbles is one way to prevent the boiling crisis at a certain condition.[6] This might allow an increase the critical heat flux by 10-20 percent and allow better fuel efficiency in power plants.[6]
