Soap Films

April 28, 2011

Computers are nice for modeling physical systems , but sometimes the model is so complex that a genral purpose computer isn't up to the task. One approach for surmounting this complexity is to advance your computer architecture , adding things such as parallelism and vector processing ; or pumping up the hardware via clusters , or the many "@home " projects.

There was a time when scientists didn't have computers. Instead of sitting on their hands (see my previous article , Everything Becomes Trivial, March 25, 2011), they were as inventive as ever in making models using physical objects. I was introduced to this idea during my senior year of high school while taking PSSC Physics . This physics course was part of the US answer to the shortage of scientists and engineers during our competition with the Russians .

PSSC Physics had some very nice laboratory modules associated with it. One experiment that caught my fancy was a simple way to measure the Earth's gravitational acceleration g. Another experiment involved the ripple tank , a shallow tank of water with a plane wave generator at one end. The ripple tank allowed visualization of optical effects, including the famous double slit experiment. The ripple tank was a physical model of wave interference.

Long before my ripple tank experiments, in fact the year I was born, a Nobel Laureate was playing with soap bubbles in the name of science. Sir William Lawrence Bragg , well known for the eponymous Bragg' Law , and John Nye were using rafts of bubbles on liquid surfaces to simulate atoms in crystals .[1-2] The duo found that glycerin -oleic acid -triethanolamine -water solutions form small, stable bubbles.

Bragg and Nye used bubble rafts to demonstrate dislocations and their reactions. In an example of Louis Pasteur's quotation that "chance favors the prepared mind," Bragg supposedly had the idea of the bubble raft while observing the bubbles formed when he was adding oil to a lawn mower.[2] Maybe that's an incentive for me to mow my lawn.

Bubble raft showing an edge dislocation.

A bubble raft from a laboratory class at MIT. This raft has bubbles that are about 1.5 mm in diameter. An edge dislocation (an inserted row of bubbles) can be seen in the lower right hand quadrant.

(Photo by Vlad Tarasov, via Wikimedia Commons, modified)

Recently, two researchers at the University of Málaga, Spain , used soap films to solve variational mathematical problems that appear in many physical systems.[3-4] Soap films can be used for such modeling since they always form with a shape that minimizes their elastic energy and area.[5]

Examples of variational problems are the brachistochrone and catenary equations. The former is the shape that a wire must have for a threaded ball to travel its length as rapidly as possible; the later is the shape of a rope or chain suspended at its ends. There's also the isoperimetric curve , which maximizes the area it encloses. The Spanish researchers found that such equations can be simulated by adjusting the boundary conditions of a soap film.

There have been other demonstrations of using soap films to investigate geometrical objects. In one case, as shown in the figure, soap film catenoids were formed between coaxial rings. The catenoid shape was monitored as a function of the distance between the rings.[6]

A soap film catenoid.

A soap film catenoid contained between two coaxial circular rings.

(Via arXiv. Fig. 4 of Ref. 6)

A Möbius loop can be formed by a soap film on a looped wire. One study investigated how wire deformation can cause a transition of a soap film from the one-sided Möbius loop topology to a two-sided film.[7-8] A wire bent into a double loop will support a soap film Möbius loop, but when the loop is untwisted, the soap film reverts to a two-sided topology. A video of the transition appears on the Proceedings of the National Academy of Science web site.[9]

Bubbles serve more than just science. On Friday, April 15, 2011, an attempt was made to enter the Guinness Book of World Records by having 37,000 people blow soap bubbles. This was the 8th Annual Blow Bubbles 4 Autism event organized by the southern New Jersey FACES Autism Support Network.[10] The present Guinness record is 34,259 people at 198 locations.
